CHENZHU REMIND YOU:

5 tips for your selection for a signal SPD

1）Maximum operating voltage Uc:

The maximum voltage of the signal circuit is less than Uc.

2）Nominal Operating Current IL

The maximum current of the circuit is less than this value.

3）Number of Wires:  2/3/4

Thermocouple is general 2-wires;

Thermal resistance is general 3-wires;

4) Other Main data:

Nominal Discharge Current In（8/20us): CHENZHU's signal SPD :C2：20kV/10kA/wire

Impulse Current Iimp（10/350us): CHENZHU's signal SPD  D1：2.5kA/wire

5) If is screwable SPD, please also pay attendtion to the male thread you need.

 1/2"NPT

 3/4"NPT

 M20×1.5
